Heating circulator MAGIO MS/MX / Julabo
For precise temperature control of internal and external applications.
-Simple control of complex applications
-Infinitely adjustable, extremely powerful pressure and suction pump
-Large, high-resolution TFT touch display with multilingual user interface
-Medium-contacting parts made of stainless steel
-Integrated programmer
-External Pt100 connection
-USB interface
-RS232 interface
-Ethernet interface
-High quality thermal insulation of the bath tanks
-Integrated drain cock for easy and safe emptying
-Classification III according to DIN 12876-1
-Simple control of complex applications
-Infinitely adjustable, extremely powerful pressure and suction pump
-Large, high-resolution TFT touch display with multilingual user interface
-Medium-contacting parts made of stainless steel
-Integrated programmer
-External Pt100 connection
-USB interface
-RS232 interface
-Ethernet interface
-High quality thermal insulation of the bath tanks
-Integrated drain cock for easy and safe emptying
-Classification III according to DIN 12876-1
| Material bath: | Stainless steel |
| Temperature: | 20 ... 300 °C |
| Temperature stability: | ±0,01 °C |
| Max. flow rate: | 31 l/min |
| Max. delivery pressure: | 0.92 bar |
| Max. suction pressure: | 0.4 bar |
| Type of display: | TFT |
| Programmable: | Yes |
| With lid: | Yes |
| Power supply: | 200 ... 230 V, 50/60 Hz |
| IP code: | IP 20 |
TypeVolume bathHeating capacity
(WxDxH)Weight
kW
Opening (WxD)Bath depthmm
Ext. dim. (WxDxH)Weight
kg
PKPrice/UnitEUR
not in stock3 ... 4.5 l2kW
130 x 150 mm150mm
230 x 410 x 420 mm11.1kg
14.454,00€
5.300,26€
incl. Tax Add tobasket
not in stock4.5 ... 6 l3kW
130 x 150 mm200mm
240 x 440 x 470 mm12.8kg
14.800,00€
5.712,00€
incl. Tax Add tobasket
not in stock8.5 ... 12 l3kW
220 x 150 mm200mm
330 x 490 x 470 mm14.6kg
15.070,00€
6.033,30€
incl. Tax Add tobasket
not in stock19 ... 26 l3kW
260 x 350 mm200mm
390 x 620 x 480 mm21.4kg
15.430,00€
6.461,70€
incl. Tax Add tobasket
not in stockTypeMS-BC4
Volume bath3 ... 4.5 l
Heating capacity
kW
2kW
Opening (WxD)130 x 150 mm
Bath depth
mm
150mm
Ext. dim.
(WxDxH)230 x 410 x 420 mm
Weight
kg
11.1kg
PK1
1 VE4.454,00
€
EUR5.300,26€
EUR incl. Taxplease selectAdd to
basket
basket
not in stockTypeMX-BC6
Volume bath4.5 ... 6 l
Heating capacity
kW
3kW
Opening (WxD)130 x 150 mm
Bath depth
mm
200mm
Ext. dim.
(WxDxH)240 x 440 x 470 mm
Weight
kg
12.8kg
PK1
1 VE4.800,00
€
EUR5.712,00€
EUR incl. Taxplease selectAdd to
basket
basket
not in stockTypeMX-BC12
Volume bath8.5 ... 12 l
Heating capacity
kW
3kW
Opening (WxD)220 x 150 mm
Bath depth
mm
200mm
Ext. dim.
(WxDxH)330 x 490 x 470 mm
Weight
kg
14.6kg
PK1
1 VE5.070,00
€
EUR6.033,30€
EUR incl. Taxplease selectAdd to
basket
basket
not in stockTypeMX-BC26
Volume bath19 ... 26 l
Heating capacity
kW
3kW
Opening (WxD)260 x 350 mm
Bath depth
mm
200mm
Ext. dim.
(WxDxH)390 x 620 x 480 mm
Weight
kg
21.4kg
PK1
1 VE5.430,00
€
EUR6.461,70€
EUR incl. Taxplease selectAdd to
basket
basket
